Install Guide

Scale Extension

Phone Cord

Cable #978-6

(Optional)

Read This First

To take advantage of the web-based capabilities of your meter with pbWebConnect™, your meter must be connected to your network.

Pitney Bowes 1e20 Printer Driver

If network access is available for your meter, you can:

Watch a step-by-step installation video by scanning the QR Code below with your smartphone

or

By entering the following URL at your computer:

www.pb.com/support/new/K7

or

Follow this printed installation guide, starting on page 1

If you do not have network access for your meter, go to page 17 “Alternative Method: Using an Analog Phone Line”

Port

Installation Part 1 - Set Up Communication Device

1 Preparing for Installation

To install your meter using the Internet, you will need the following:

Two power outlets

An Internet source, such as a router, hub or network wall jack.

Note: DO NOT use a port in a computer to connect to your network.

Access to a computer during installation is recommended.

Wireless: Step 2 through Step 8 must be completed for wireless installation.

Technical Requirements:

IP Address

-Automatic assignment with DHCP and DNS server capability, or

-Manually specified static IP (not shared with other devices on your network).

If your network requires special settings, such as static IPs or proxy settings, your IT specialist should use the Special Network Settings instructions in this booklet, as part of the installation.

Pitney bowes 1e20 printer driver

Proxy Server (if needed)

If your network uses Static IPs or Proxies, the setup software requires: Operating System:

Port

Windows 2000, Windows XP, Windows Vista, Windows 7

Mac OS X (PowerPC: Ver10.3.x ~ Ver10.5.5)

Compatible Browsers:

Internet Explorer 7.x, 8.x, 9.x, Chrome 16.x, 17.x, 18.x, Firefox 10.x, 11.x, 12.x Safari 5.1

Installation Part 1 - Set Up Communication Device

2Locate the Communication Device and Network Cable ()

Pitney bowes print drivers

The Communication Device enables your meter to connect to Pitney Bowes via the Internet to access postage downloads. It’s packaged in its own cardboard box.

Communication Device

For Pitney Bowes Digital Mailing System

Communication Device Network Cable

3Connect the Communication Device to your Internet source

Be sure to connect to an active network port.

Note: If you are not certain where to connect, or whether your network requires special settings, consult your IT specialist.

Internet Source

Router, Hub, Wall Jack

Communication

DO NOT use a port in a

Network Cable

Device

computer to connect to

your network.

Installation Part 1 - Set Up Communication Device

4Apply power to Communication Device

Plug the AC adapter ( ) into the Communication Device and a power outlet. The left LED is lit yellow when it is on.

LEDs

Communication

Device

AC Adapter

5Check LED

After 45 seconds, the right LED will blink orange, go to Step 6

LEDs

If the right LED is solid orange (not blinking), follow Troubleshooting 1, below.

Troubleshooting 1

Communication Device may not be communicating to an active network port. Try the following:

Be sure the Network Cable () is properly connected at both ends.

Try other ports (for 10 seconds each) until you find one that is active

(LED changes from solid orange to green). Do not use a network port in a computer.

Pull the power connector () out, then reconnect power to restart the Communication Device.

If after 45 seconds, the right LED is still not blinking orange only, consult your IT specialist. Your IT specialist may need to follow the Special Network Settings procedure on page 6.

For more detailed technical assistance, go to: www.pb.com/support/LAN

3

Installation Part 1 - Set Up Communication Device

Drivers Pitney Bowes Port Devices Terminal

6 Connect the meter to the Communication Device with the USB Cable ()

USB Cable

7 Connect the meter to a power outlet

Power Cord

When power is applied, the meter will display its startup screens and you will hear the meter’s printer initialize.

If the right LED lights orange, either solid or blinking, see Troubleshooting 2 below.
For wireless connection and meter setup go to Step 9 on page 7.
If the meter does not display the message, “ Meter connected to Internet”, your meter is not communicating with the Internet.
Also, the right LED changes from blinking orange to blinking green only.
Confirm Connection
About 10 seconds after the meter completes its startup routine,
Meter connected to internet-Press Enter

Installation Part 1 - Set Up Communication Device

8

Check that the USB Cable () is connected properly.

If the right LED is solid orange (not blinking), then the network cable is connected to an inactive port. Try other ports (for 10 seconds each) until you find one that is active (LED changes from solid orange to green).

Restart the Communication Device by pulling the power connector () out, then reconnecting the power.

If, after 60 seconds the message, “Meter connected to internet” is not displayed, consult your IT specialist.

Your IT specialist can refer to online troubleshooting assistance at: www.pb.com/support/LAN

Pitney bowes service request

Special Network Settings

This section is needed only if your network requires special settings to operate properly, such as static IPs and proxy server IDs, the settings will need to be added to the Communication Device.

Consult your IT specialist to determine if this is necessary.

To enter special settings

a.Disconnect power () from the meter.

b.Be sure the Communication Device is:

-connected to an active Internet port

-plugged into a power outlet

Pitney Bowes K700 Driver Download

-the right LEDs are blinking in an orange and/or green pattern.

c. Download the setup software to your computer by going to: www.pb.com/support/netsetup.

Click the button for your type of computer.

Note: If a firewall message appears, click the button that allows the download to proceed.

d.Save the software “pbSmartLAN” to your computer, then open and run it.

e.Click the Setup for Network Cable Connection button.

Pitney Bowes Driver Download

Follow the setup wizard and enter the appropriate special settings.
